Standard Flagpoles





Specifications


The staff is made from laminated structural grade timbers.
Tabernacle is made from galvanised steel, bolted together with galvanised bolts.
The Tabernacle goes beneath the ground level by approximatly 26" to 32" and is concreted in place.

Treated with penetrating epoxy wood preserver and finished white with marine quality two pack paint system.
The turned wooden truck houses the bronze halliard sheave. The halliard is ¼" yacht braid fitted with flag clips. A traditional cleat is fitted for making it fast.


Dimensions


3 standard sizes available:
20' (6 metres)
26' (7.8 metres)
30' (9.2 metres)

* add about 4" for tabernacle to calculate height of pole above ground.

Special orders are invited including flagpoles with yards, gaffs and topmasts.

A Gaff and Yardarm are available to attach to the standard 30' flagpole.







Mark

Yardarm Flagpoles



These poles are great for Yacht clubs, large homes or any site that requires a nautical feel or display of multiple flags.

Specifications


The staff, yard, gaff and topmast are made from laminated structural grade timbers.
Treated with penetrating epoxy wood preserver and finished white with marine quality two pack paint system.
Tabernacle is made from galvanised steel, bolted together with galvanised bolts.
The Tabernacle is concreted in place.
The turned wooden truck houses the bronze halliard sheave. The halliard is ¼" yacht braid fitted with flag clips.
A traditional cleat is fitted for making it fast.


Dimensions


3 standard sizes available:

30' (9.2 metres)

Yard length: 126" (3.2 metres)
Gaff length: 142" (3.6 metres)

40' (12.2 metres)

Yard length: 157 ½" (4 metres)
Gaff length: 193" (4.9 metres)

60' (18.3 metres)

Yard length: 191" (7.4 metres)
Gaff length: 240.2" (6.1 metres)


Mark
