Deal Island 50






The Deal Island 50 is the result of many years of experience in cruising and development, she represents the best of the best, and is a testament to years spent cruising in and around the Australian coastline.













Overview


The Wooden Boatshop was founded on the re-visioning of classic and traditional style working boats, to use for leisure, for luxury, and for racing, and to be experienced amongst family and friends.

The Deal Island 50 is fitted for comfort and style, she is luxurious in her size and cruising capability. She is a classic combination of wood and bronze, made entirely by hand from beginning to end.











Specifications

Length       50’
Beam        15’
Draft        3’11”
Power      Volvo Penta D13 1000 hp

Top Speed        28 knots

Cruising Speed        18 knots

Fuel Capacity       1900L
Water Capacity        700L
Displacement       13.25 tons








The main engine, a Volvo Penta D13 1000 hp, drives a hydraulic pump and this system powers a 24v alternator, bow thruster and anchor winch. The 24v alternator is hydraulically driven at constant speed and produces 300amps. This allows the battery system to be charged from flat to full in less than three hours. This streamlines the electrical system, saves weight and improves reliability. The electrical system is built with a 600 AH lithium house battery bank. The system can rapidly charge from empty to full and delivers any required power demand of power due to the lithium batteries capability of being cycled all the way down. The lithium battery system at about $3.18 per cycle is about 40% cheaper than comparable AGM or Gell batteries. The 24v lithium battery has an 800Ah capacity. The air conditioning is able to run on battery for 5-6 hours. It is able to store about as much energy as the average house uses in a day.





“We achieved over 15 knots at 1500RPM with less than 40% engine load, This is a magnificent boat, It would be very hard to step back on any other boat.”

TIM PHILLIPS
Director, The Wooden Boatshop
